Product details
Technical parameter
| ltem/model | VPD250X | VPD350X |
| Packaging form | Horizontal Four-side sealinq | |
| Package material | CPP film. PE film. BOPP film | |
| Inner material | ( Air laid paper,nonwoven,spun lace nonwoven fabric etc) | |
| Raw material inner roller diameter | ⑦70-75mm | ⑦70-75mm |
|
Packing specification |
40-125mm | 80-175mm |
| Folding way | Max 10 foldinci vertical，and 4 foldina horizontal | |
| Liquid added range | 0-5ml | 0-5ml |
| Packing speed | 120-220(bags/min) | 120-220bags/min) |
| Total power | 8.OKW | 8.OKW |
| Power supply type | 380V 60Hz | 380V 60Hz |
| Machine noise | <80db (A) | <80db (A) |
| Air supply | 0.7-1.0 MPa | 0.7-1.0 MPa |
| Air consumtion | 300-500mL/min | 300-500mL/min |
| Outline dimensions | 3500x2800x1800mm ( L*W*H ) | 3500x2800x1800mm ( L*W*H ) |
| Machine weight | 1500kg | 1600kg |
